ESA Text HMI VT520G000 Membrane Keypad Replacement

group name: VT Text & Graphic

Min Order: 1 piece

brand name: VICPAS

model: VT520G000

Nearest port for product export: Guangzhou, Hongknog, Shenzhen, Taiwan

Delivery clauses under the trade mode: FOB, CFR, CIF, EXW, FAS, CIP, FCA, CPT, DEQ, DDP, DDU, Express Delivery, DAF, DES

Acceptable payment methods: T/T, L/C, D/P D/A, MoneyGram, Credit Card, PayPal, Westem Union, Cash, Escrow

update time: Fri, 22 Nov 2024 13:39:01 GMT

contact supplier

Paramtents

Brand ESA
Warranty 180 Days
Product Line VT Text
Supply VT520G Membrane Keypad

Packging & Delivery

Min Order1 piece

Briefing

ESA HMI VT520G VT520G000 Operator Panel Membrane Keypad. 6-months Warranty-Fully Tested-Factory Prices-Fast Shipping

Detailed

ESA TEXT HMI VT520G VT520G000 Membrane Keyboard Replacement

ESA TEXT HMI VT520G VT520G000 Membrane Keyboard Repair Replacement

VT520G000 with graphic LCDdisplay, 256 colors, 30 rows by80 characters, VGA (640 x 480),MSP (RS232/422/485/TTY), ASP(RS232/485), LPT (Centronics), 2,3MB project, clock, 256 KB recipes, 74operative keys (28 function keys, 16customizable)

ESA VIDEO TERMINAL (VT) is a device that allows the user to control orsimply monitor a productive process. It can send commands using configuredby the user; it can send data determining the process on hand andcan display information deriving from the productive process. The informationcan be in the form of an Alarm, an Information (Info-) Message or inbinary data format.

VICPAS supply ESA TEXT HMI VT520G membrane switch with 6 months warranty and support Urgent Worldwide Shipping.

Contact Best Price

Specifications:

The table below describes the parameters of the ESA VT520G000 HMI Parts.

Brand:	ESA
Display Type:	Graphic LCD 256 colors TFT
Resolution:	640 x 480
Warranty:	6-Months Warranty
Product Line:	VT TEXT

Display Backlight:	CCFL
Display area size:	211,2 x 158
Columns by Rows:	Depending on used Font
Function key LEDs:	46
Part Number:	VT520G000

ESA VT520G Operator Panel HMI Manuals PDF Download:

ESA HMI VT Series Manuals

ESA VT TEXT HMI datasheet pdf

FAQ:

Question: How to adjust the contrast on the ESA VT520G Display?

Answer:To improve the quality of the representation on the display it may be necessaryto adjust its contrast. This can be done by rotating the trimmer (C) atthe back of the VT ; turn it (using a small screwdriveror a trimmer tool) in one direction and, if the display quality worsens,turn it the other way.

Question: What is the VT520G000 Termination of CAN line?

Answer:The VT VT520G000 in question integratesthe termination resistances of the serial line (typically 120 ohms)which can be inserted by means of a jumper (preset on 1-2, line not terminated).To activate the termination:
• Make sure the device is not connected to the power supply.
• Remove the cover.
• Identify the jumper unit J2.
• Position the jumper between pins 2 and 3 (line terminated).
• Replace the back cover.
• Reconnect the power supply.

Question: What is ESA VT520G VT520G000 mebrane keyboard HMI parts price?

Answer: Submit a fast quote, send VICPAS an email for best price.
