6FC5203-0AF10-2AA0 Siemens OP010FS Membrane Keyboard
- group name
- SINUMERIK Operator Panel
- Min Order
- 1 piece
- brand name
- VICPAS
- model
- 6FC5203-0AF10-2AA0
- Nearest port for product export
- Guangzhou, Hongknog, Shenzhen, Taiwan
- Delivery clauses under the trade mode
- FOB, CFR, CIF, EXW, FAS, CIP, FCA, CPT, DEQ, DDP, DDU, Express Delivery, DAF, DES
- Acceptable payment methods
- T/T, L/C, D/P D/A, MoneyGram, Credit Card, PayPal, Westem Union, Cash, Escrow
- update time
- Fri, 22 Nov 2024 05:00:28 GMT
Paramtents
Brand Siemens
Warranty 6 Months
Product Line Siemens OP010FS Operator Panel
Supply Sinumer HMI OP010FS Membrane Keyboard Plastic Case
width 444.5mm
height 289mm
model 6FC5203-0AF10-2AA0
Packging & Delivery
-
Min Order1 piece
Briefing
Detailed
6FC5203-0AF10-2AA0 Siemens SINUMERIK HMI OP010FS OPERATOR PANEL Keypad Membrane and Plastic Case Shell Repair Replacement
Description
Siemens OP010FS 6FC5203-0AF10-2AA0 Housing Keyboard Membrane SINUMERIK operator panel front: 10.4 Membrane keyboard
The extremely compact SINUMERIK operator panel front OP 010FS 6FC5 203-0AF10-2AA0 Membrane Keypad Switch HMI Case allows the operator panel front and control to be separately installed (distributed architecture). The SINUMERIK operator panel front OP 010FS includes a membrane keyboard with 65 keys (the layout is the same as the SINUMERIK CNC full keyboardKB 310C) as well as 2 x (8+2) horizontal and 2 x 8 vertical softkeys. The distance to the operator panel fronts of 6FC52030AF102AA0 is determined by the maximum distance between two network nodes/access points. The operator panel front is attached from the rear using the already known clamping clips that are included in the scope of supply.
The SINUMERIK operator panel front OP 010FS 6FC5203-0AF10-2AA0 Membrane Switch Plastic Cover is coupled to the PCU/NCU as thin client in a dedicated sub-network (via DHCP server on the PCU/NCU) via Ethernet.Connections (ports):2 x USB 1.1Ethernet 10/100 Mbit/s
Hot Keys of 6FC5 203-0AF10-2AA0 Keyboard Membrane HMI Case
• By pressing this key of 6FC5, the last opened screen in Start-up Operating Area can be displayed.
• By pressing this key, the last opened screen in Machine Operating Area can be displayed.
Operator Panel of 6FC52030AF102AA0 HMI Housing Keypad Membrane
OP010FS 6FC5203-0AF10-2AA0 Operator Panel Keypad Plastic Cover is used for Yaskawa Siemens CNC Series. Beside there are two types of the keyboard for OP010FS,i.e. QWERTY type and ABCD type, concerning arrangement and illustration of each key. For differences between these keyboards, please refer to Section 8.1 "Comparison table for keys".
VICPAS supply 6FC5 203-0AF10-2AA0 Siemens OP010FS membrane switch with 6 months warranty and support Urgent Worldwide Shipping.
Specifications:
The table below describes the parameters of the 6FC5203-0AF10-2AA0 Siemens OP010FS HMI Parts.
| Combination: | TCU or PCU |
| Number of Lines: | 2 |
| Character Size: | 5 mm |
| Warranty: | 6-Months Warranty |
| Product Line: | Siemens OP010FS |
| Screen Diagonal: | 10.4 in TFT |
| Part Number: | 6FC5203-0AF10-2AA0 |
| Input Voltage: | DC 5 V |
| Design as Touch Screen: | No |
| Design of Display: | LC display |
Related Simatic OP010FS Part No. :
| SINUMERIK OP10FC Keypad | Description | Inventory status |
| 6FC5203-0AF10-1AA0 | Siemens SINUMERIK HMI OP010FS Terminal Keypad Housing Repair | In Stock |
| 6FC5203-0AF10-2AA0 | Siemens OP010FS HMI Case Membrane Switch Replacement | Available Now |
| 6FC5203-0AF10-2AA1 | Siemens SINUMERIK Operator Keyboard Shell Cover Repair | In Stock |
| 6FC5247-0AA24-0AA1 | Siemens OP010FS Keypad Membrane HMI Cover Replacement | In Stock |
| 6FC5247-0AA25-1AA0 | Siemens OP010FS Housing Membrane Keypad Switch Repair | Available Now |
| 6FC5248-0AF11-0AA0 | Siemens SINUMERIK Keyboard Membrane Plastic Case Replacement | In Stock |
| Siemens OP10FC Part No. | Description | Inventory status |
Siemens OP010FS series HMI Manuals PDF Download:
FAQ:
Question:What is Siemens SIMATIC OP010FS function?
Answer:
•Signals are transferred between the operator panel front and PCU/NCU via Industrial Ethernet
•Simple mounting and installation
•Mixed operation with one operator panel front directly at the PCU is possible. Operator control at an OP 010FS has the same level of authorization (peer) as operator control of an OP010FS connected
•directly at the PCU. A darkened image is shown on the passive operator panel.
•The distance is defined by the maximum distance between two network nodes/access points (100 m).
Question: What is the size of 6FC5203-0AF10-2AA0 Siemens OP010FS membrane switch??
Answer: It is 444.5 millimeter long and 289.5 millimeters wide.
Question: What is the 6FC5203-0AF10-2AA0 Siemens OP010FS mebrane switch and shell HMI parts price?
Answer: Submit a fast quote, send VICPAS an email for best price.
Common misspellings:
6FC5203-0AF10-2AA06C5203-0AF10-2AA0
6F5203-0AF10-2AA0
6FC5203-0AF10-22AA0
6FC5203-0AF10-2AAA0
