B&R 5MP050.0653-04 Touch Panel Membrane Keypad

group name: Mobile Panel

Min Order: 1 piece

brand name: VICPAS

model: 5MP050.0653-04

Nearest port for product export: Guangzhou, Hongknog, Shenzhen, Taiwan

Delivery clauses under the trade mode: FOB, CFR, CIF, EXW, FAS, CIP, FCA, CPT, DEQ, DDP, DDU, Express Delivery, DAF, DES

Acceptable payment methods: T/T, L/C, D/P D/A, MoneyGram, Credit Card, PayPal, Westem Union, Cash, Escrow

update time: Sat, 01 Nov 2025 04:11:07 GMT

contact supplier

Paramtents

Brand B&R
Size 6.5 inch
Model B&R Mobile Panel 50 5MP050.0653-04
Shipping DHL/FedEx/UPS/TNT/EMS/Aramex /DPEX
Warranty 1 Year VICPAS Warranty

Packging & Delivery

Min Order1 piece

Briefing

B&R Mobile Panel 50 5MP050.0653-04 Keyboard Membrane Touch Screen Panel. 1 Year Warranty-Fully Tested-Worldwide Shipping

Detailed

B&R Mobile Panel 50 5MP050.0653-04 Touch Screen Glass Membrane Keypad Repair

Order each part separately is available

Mobile Panel 50 5MP050.0653-04 Touch Digitizer Membrane Keypad Switch

Control and display panel
• Membrane keys with mechanical pressure point
• 4 (on MP40) or 7 (on MP50) LED status indicators
• Buzzer

An MP100/200 can be connected to the system in place of an MP40/50. The attachment cables feature the same circular connectors allowing for simple exchange by removing and inserting. When connecting an MP40/50, the differences between the devices must be taken into consideration.

5MP050.0653-04 Electronics
• CPU Intel PXA270/416 MHz
• Memory expansion:
° SDRAM: 256 MB
° FLASH: 128 MB

Contact Best Price

Specifications:

The table below describes the parameters of the 5MP050.0653-04 Mobile Panel 50 Touch Digitizer Membrane Keypad Switch.

Part Number :	5MP050.0653-04
Product Line:	Mobile Panel 50
Screen diagonal:	6.5 in
Warranty:	365 Days Warranty
Input Power:	24 VDC

Display Type:	TFT color
Mounting position:	Vertical
Input Type:	Keypad
Serial interface Type:	RS232
Storage:	-20 to 70°C

Related B&R Series Part No. :

B&R Mobile Panel 50	Description	Inventory status
5MP050.0653-01	B&R Mobile Panel 50 Touch Screen Panel Glass Operator Keyboard	In Stock
5MP050.0653-02	Mobile Panel 50 Touch Panel Glass Keyboard Membrane Replacement	Available Now
5MP050.0653-03	B&R Mobile Panel 50 Touch Screen Panel Switch Membrane Repair	In Stock
5MP050.0653-04	B and R Mobile Panel 50 Touch Digitizer Membrane Switch Replacement	Available Now
5MP050.0653-K01	Mobile Panel 50 HMI Touch Screen Organizer Switch Membrane	Available Now
5MP050.0653-K03	Mobile Panel 50 Touch Panel Membrane Switch Keypad Repair	In Stock
5MP050.0653-K04	Mobile Panel 50 HMI Touch Screen Monitor Keypad Membrane	Available Now
5MP050.0653-K05 REV.E0	Mobile Panel 50 HMI Touch Glass Membrane Keypad Overlay	In Stock
B and R MP50	Description	Inventory status

B&R Mobile Panel 50 Manuals PDF Download:

B&R Mobile Panel 40/50 User's Manual

Mobile Panel 40/50 Product Datasheet

FAQ:

Question:What is Image Persistence of 5MP050.0653-04?

Answer: Image persistence refers to the "burning in" of a static image on a display after being displayed for a long time. It does not only occur with static images, however. Image persistence is also referred to in the technical literature as screen burn-in, image retention, memory effect, memory sticking or ghost image.
There are 2 different types:
• Area type: This type can be seen in a dark gray image. The effect disappears if the display is switched off for a long time.
• Line type: This can result in permanent damage.

Question:How can 5MP050.0653-04 image persistence be reduced?

Answer:
• Switch continuously between static and dynamic images.
• Prevent excessive differences in brightness between foreground and background elements.
• Use colors with similar brightness.
• Use complementary colors for subsequent images.
• Use screensavers.
