4D1166.00-K04 Keypad Membrane Switch LCD Screen Repair

group name: PANELWARE

Min Order: 1 piece

brand name: VICPAS

model: 4D1166.00-K04

Nearest port for product export: Guangzhou, Hongknog, Shenzhen, Taiwan

Delivery clauses under the trade mode: FOB, CFR, CIF, EXW, FAS, CIP, FCA, CPT, DEQ, DDP, DDU, Express Delivery, DAF, DES

Acceptable payment methods: T/T, L/C, D/P D/A, MoneyGram, Credit Card, PayPal, Westem Union, Cash, Escrow

update time: Sat, 22 Feb 2025 16:36:59 GMT

contact supplier

Paramtents

Brand B&R
Membrane Material Plastic
Model B&R PANELWARE 4D1166.00-K04
Warranty 1 Year VICPAS Warranty
Shipping DHL/FedEx/UPS/TNT/EMS/Aramex /DPEX

Packging & Delivery

Min Order1 piece

Briefing

B&R PANELWARE 4D1166.00-K04 Keyboard Membrane LCD Display. It is brand new and good quality with a 6 months warranty.

Detailed

B&R PANELWARE 4D1166.00-K04 LCD Screen Membrane Keypad Keyboard Repair

Order each part separately is available

B&R PANELWARE 4D1166.00-K04 LCD Display Screen Keypad Membrane

Energy provision for the electronics of the B&R PANELWARE 4D1166.00-K04 Terminal Keypad LCD Display Panel MMI is done from the controller in order to save on volume and power in the panel. A 2 x 20 character LCD is used as the 4D1166.00-K04 display. A 4D1166.00-K04 LED background lighting with an automatic shut-off and a practically unending life expectancy has also been integrated. In addition to the alphanumeric display, operator guidance is also assisted with key LEDs.

The B&R PANELWARE 4D1166.00-K04 LCD Display Membrane Keyboard COMPACT MMI in combination with the COMPACT PLC BRCOMP1-0 makes an extra low cost and very attractive automation package (control and visualization). It is also possible to use the COMPACT MMI with a MINI, MIDI, MULTICONTROL or an M264. All 4D1166.00-K04 keys are equipped with key LEDs which can be switched on and off individually. The key LEDs can be used to make application control easier to see and to simplify panel operation. To control a certain LED, the respective key code (x) is given (valid key codes can be found under point "Key Code Requests").

Contact Best Price

Specifications:

The table below describes the parameters of the 4D1166.00-K04 B&R PANELWARE Membrane Keypad Keyboard LCD Screen.

Part Number:	4D1166.00-K04
Product Line:	PANELWARE
Warranty:	365 Days Warranty
Input Power:	24 VDC

Display Type:	TFT color
Mounting Position:	Vertical
Input Type:	Keypad
Serial Interface Type:	RS232

Related B&R PANELWARE Series Part No. :

B&R PANELWARE	Description	Inventory status
4B1260.00-K03 Rev.B0	B&R PANELWARE Operator Keyboard Repair	In Stock
4B1260.00-K06	PANELWARE B and R Keyboard Membrane Replacement	Available Now
4B1260.00-K09	B&R PANELWARE Switch Membrane Repair	In Stock
4B1270.00-K04	PANELWARE B and R HMI Terminal Keypad	Available Now
4C1300.02-510	B&R PANELWARE Keyboard Membrane Repair	In Stock
4D1165.00-590	B&R PANELWARE Membrane Keypad Keyboard	In Stock
4D1166.00-590	B&R PANELWARE Switch Membrane Repair	In Stock
4D1166.00-K04	B and R PANELWARE Membrane Keypad LCD Screen	Available Now
4D1166.00-K19	B&R PANELWARE HMI Switch Membrane Repair	Available Now
4PW035.E300-K09	PANELWARE Keyboard Membrane LCD Display Plastic Case Replacement	In Stock
B and R PANELWARE	Description	Inventory status

B&R PANELWARE Manuals PDF Download:

B&R PANELWARE P120 COMPACT HMI User's Manual

B&R PANELWARE Hardware and Installation Manual

FAQ:

Question: How to remove B and R PANELWARE COMPACT 4D1166.00-K04 MMI?

Answer:
• Remove spring clips
How to remove B and R COMPACT MMI?
• Remove panel
• Remove and reapply sealant before a new installation
• The mounting pins do not have to be removed

Question:How can the PANELWARE 4D1166.00-K04 service life of backlights be extended?

Answer:
• Set the display brightness to the lowest value comfortable for the eyes.
• Use dark images.
• Reducing the brightness by 50% can increase the half-brightness time by approximately 50%.
